| 产品编号 Model Number | GZ151304 | GZ161404 | |
| 工作高度working height | mm | 15800 | 16000 |
| 平台高度platform height | mm | 13800 | 14000 |
| 额定载荷Whole weight | kg | 230 | 320 |
| 收起时最大高度（栏杆立起）Folding maximum height(guardrail unfolding) | mm | 2600 | 2740 |
| 收起时最大高度（栏杆拆除）Folding maximum height(guardrail removed) | mm | 2200 | 2229 |
| 整机长度Overall Length | mm | 2760 | 2830 |
| 整机宽度Overall Width | mm | 1250 | 1500 |
| 工作平台尺寸Platform Size | mm | 2640*810 | 2800*1450 |
| 工作延伸尺寸Platform extend size | mm | 900 | 1100 |
| 最小离地间隙（收拢状态）Minimumground clearance(folding) | mm | 100 | 200 |
| 最小转弯半径（内轮） Minimum turn radius(inner wheel) | mm | 0 | 0 |
| 最小转弯半径（外轮） Minimum turn radius(outer wheel) | mm | 2560 | 5800 |
| 动力源Power source | v/kw | 24V/3.5 | 48V/5Kw |
| 机器行使速度（收拢状态）Running speed(folding) | km/h | 3.4 | 3.4 |
| 机器行使速度（起升状态）Running speed(rising) | km/h | 0.8 | 0.8 |
| 上升/下降速度Rising/falling speed | sec | 75-85 | 70/80 |
| 蓄电池Battery | V/Ah | 6×4/300 V/Ah | 8×6/216V/Ah |
| 充电池Charger | V/A | 24/25V/A | 48/30-40 V/A |
| 最大爬坡能力Maximum climbing ability | % | 25 | 20% |
| 工作最大允许角度Maximum working allowable angle | / | 2-3° | 2-3° |
| 控制方式Way of control | / | 电动控制 | 电动控制 |
| 驱动Driver | / | 双前轮 | 双前轮 |
| 液压制动Hydraulic drive | / | 双后轮 | 双后轮 |
| 整体重量Overall Net Weight | kg | 3360 | 4100 |
